Airmax 2-7×32 AO AMX
Specialist scopes designed by airgunners for airgunners!
Airmax scopes feature our H2 optics in a variety of configurations designed to suit airgun characteristics.
AMX Reticle
Both the AMX and AMX IR glass etched reticles are based on the spacing of a 10x Mil Dot. The AMX offers multiple aim points, useful when shooting air guns with loopy trajectories.
Half Mil Dot spacing on the lower post provides increased aim points for long shots.
The horizontal bars are calculated at 0.5, 1.5, 2.5, 3.5 and 4.5 mil spacing. Hollow posts are segmented into mil spacing and can be used for bracketing.
Key Features:
- Capped Low-Profile Turrets
- 1 Inch Mono-tube chassis
- Wide Angle
- 16 layer Fully Multi-Coated lenses
- High torque zoom ring
- Fast focus eyebell
- AMX reticle designed for airguns
Specification
| Optical System | System H2 |
| Scope Tube | 1 Inch |
| Magnification | 2 – 7x |
| Objective Lens | 32mm |
| Reticle | AMX |
| Parallax | Adjustable Objective |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated – 16 Layers |
| Field of View | 52.5 – 18.9 ft @100yds / 17.5 – 6.3 m @100m |
| Field of View (°) | 10 – 3.6 |
| Eye Relief | 3.5 in / 90 mm |
| PX/Focus | 7.5 yds – ∞ / 7 m – ∞ |
| Exit Pupil | 0.63 – 0.18″ / 16 – 4.6 mm |
| Click Value | ¼ MOA |
| Turret Type (Elevation) | Capped, Low-Profile, Resettable |
| Elevation Turret Clicks (max) |
